Engine

Performance & Transmission

Maximum power	228.0 kW {310 PS} / 14,000 rpm
Maximum power with RAM Air	240.0 kW {326 PS} / 14,000 rpm
Maximum torque	165.0 N•m {16.8 kgf•m} / 12,500 rpm
Transmission	6-speed, return shift
Clutch	Wet, multi disc
Primary reduction ratio	1.551 (76/49)
Gear ratios 1st	3.188 (51/16)
Gear ratios 2nd	2.526 (48/19)
Gear ratios 3rd	2.045 (45/22)
Gear ratios 4th	1.727 (38/22)
Gear ratios 5th	1.524 (32/21)
Gear ratios 6th	1.348 (31/23)
Final drive	Sealed chain
Final reduction ratio	2.333 (42/18)

Frame & Dimensions

Frame type	Trellis, high-tensile steel
Trail	108 mm
Wheel travel front	120 mm
Wheel travel rear	135 mm
Tyre, front	120/600 R17
Tyre, rear	190/650 R17
L x W x H	2,070 x 850 x 1,160 mm
Steering angle L/R	27° / 27°
Wheel base	1,450 mm
Ground clearance	130 mm
Fuel capacity	17.0 litres
Seat height	830 mm
Curb mass*	216 kg
‎	*Curb mass includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
Estimated dry weight**	196 kg
‎	**Estimated Dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).

Brakes & Suspension

Front brake type	Dual semi-floating Brembo discs
Front brake diameter	Ø 330 mm
Front brake caliper type	Brembo radial-mount, Stylema monobloc, opposed 4-piston
Rear brake type	Single disc
Rear brake diameter	Ø 250 mm
Rear brake caliper type	Brembo, opposed dual-piston
Front suspension type	Inverted fork with compression and rebound damping, spring preload adjustability, and top-out springs
Front suspension diameter	Ø 43 mm
Rear suspension type	Uni-Trak, Öhlins TTX36 gas-charged shock with piggyback reservoir, compression and rebound damping, spring preload adjustability, and top-out spring
